Design /Application Data
The SHL012 12W Slab Hanging LED Light is designed to deliver focused and efficient illumination for slab-hanging and architectural lighting applications. Compact yet powerful, it features high-efficiency LEDs that provide bright, uniform light with low energy consumption. Built with a sturdy, corrosion-resistant housing, it ensures long-lasting performance in both indoor and outdoor environments. Easy to install and visually sleek, the SHL012 is an ideal lighting solution for wet and dry applications, enhancing structural elements and decorative installations with a clean and modern lighting effect.
Specification Data
| Model | SHL012 |
|---|---|
| Voltage | 12V DC |
| Wattage | 12W |
| Light Colour | RGB, WARM WHITE |
| Blub Type | LED |
| Beam Angle | 10°/ 25° |
| Dominant Wavelength (RGB) (nm/k) | R:620-630 G:520-535 B:465-485 |
| Luminous Flux | 100 LM/W |
| Operating Temperature | -20 - + 50°C |
| Storage Condition | -40 -+80°C, 10-95% RH |
| Cable | H07RN-F CABLE 2.5 MTR LENGTH |
| Protection Class | IP68 |
| Casting | STAINLESS STEEL316 |
